EPC2160-A01
The EPC2160-A01 is a 21.5-inch FHD fanless panel PC with an industrial motherboard, perfect for various industrial uses. It offers a 1920 x 1080 resolution and 500 cd/m² brightness.
Overview
The front panel has a sleek, narrow bezel design and meets IP65 standards, ensuring durability in industrial settings. It features dual 2.5 Gigabit Ethernet ports, a Mini PCIe slot, and two M.2 slots for connecting to LAN, WLAN, and 5G networks, along with various storage options.
The EPC2160-A01 can also connect to a second display via DP and USB-C, and includes two adjustable RS-232/422/485 ports, making it an excellent choice for integrating with industrial equipment.
Key features
- 16:9 21.5” FHD fanless LED panel computer
- Intel® Processor N97, Quad Core 2.0GHz, 6M Cache
- 10 points P-Cap multi-touch with zero bezel flush front design
- 1 x DDR5 4800MHz with default 8GB installed
- Additional 2nd Display: 1 x DP/1 x USB-C
- Dual Intel® 2.5GbE LAN ports, 2 x USB 3.2, 1 x Line out
- 2 x RS-232/422/485, 1 x RS-232, 1 x Mini PCIe, 2 x M.2
- IP65 compliant front panel
- Mounting support: panel/wall/stand/VESA 100mm x 100mm
- DC power input 24V DC
Choose your product
Ordering Information
| Part Number and Description | |
|---|---|
| EPC2160-A01 | Contact Your Local Sales |
Validated technical specifications of our products are exclusively available in PDF documents named "Datasheet," which can be downloaded from the product page on our website.
