eCC3910E
The eCC3910 series, equipped with 12th and 13th Gen Intel® Core™ i9/i7/i5/i3 processors, is a fanless PC tailored for industrial automation and edge computing, offering high CPU and graphics performance.
Overview
eCC3910E supports up to 64GB of DDR5 memory and provides various storage options, including M.2, HDD, SSD, and mSATA. The series accommodates a wide DC input range from +12V to 30V and operates in temperatures from -20°C to 60°C.
For enhanced connectivity, it features an internal mini-PCIe socket for IoT wireless applications, supporting optional Wi-Fi, 3.5G, 4G LTE, and 5G modules via M.2 3052 Key B.
Downloads
Key features
- Support 12/13th Gen Intel® Core™ i3/i5/i7/i9 LGA1700 socket type
- 1 x Outside accessible M.2 2242 Key M with PCIe x4, support NvME embedded processor
- 6 x USB 3.2 Gen 1, 4 x USB2.0
- Intel® Q670E PCH
- 2 x Isolated RS232/422/485 with auto-flow and 1 x RS232
- Support 2 x DDR5 SO-DIMM socket, up to 64GB
- 1 x mini-PCIe slot, support optional Wi-Fi, 3.5G, 4G LTE
- Four Intel® i226-IT LAN ports, support WoL, teaming, and PXE
- 1 x 2.5” SATA HDD/SSD (additional 1 x 2.5” SATA upon request)
- 1 x DP, 1 x HDMI®, and 1 x VGA with independent display TPM 2.0 default onboard
- 1 x M.2 3042/3052 Key B support LTE/5G module
Choose your product
Ordering Information
| Part Number and Description | |
|---|---|
| eCC3910E | Contact Your Local Sales |
Validated technical specifications of our products are exclusively available in PDF documents named "Datasheet," which can be downloaded from the product page on our website.
