eCC70

The eCC70 is a fanless PC powered by the latest Intel® Core™ and Celeron® processors, ideal for industrial applications that require low power usage and multiple I/O interfaces in a compact space. It operates efficiently in temperatures from -10°C to 60°C and accepts DC power inputs from 12V to 24V.

eCC70

Overview

The eCC70 supports four independent displays and up to 32GB of DDR4 3200MHz memory. The eCC70 offers robust connectivity with an Ethernet LAN port and a serial port for Modbus TCP or Modbus RTU communication.

For wireless options, it includes a mini-PCIe socket and an M.2 socket for adding Wi-Fi, Bluetooth, 4G LTE, 5G, and storage modules, making it an excellent choice for M2M intelligent systems and IoT gateways.

Key features

  • Onboard Intel® 11th Core-i/ Celeron processor
  • 4 x HDMI
  • 3 x USB 3.0, 1 x USB 2.0
  • 1 x RS232/422/485, 1 x RS232
  • 3 x GbE LAN ports; support WoL, teaming and PXE
  • Onboard TPM 2.0 chip
  • 1 x M.2 socket for storage/4G LTE/5G modules
  • 1 x mini-PCIe socket support optional mSATA/Wi-Fi/BT/4G LTE module
  • Support operating temperature from -10°C to 60°C
  • Support+12V to 24VDC input; support ATX power mode

Choose your product

Ordering Information

Part Number and Description
eCC70 Contact Your Local Sales

Validated technical specifications of our products are exclusively available in PDF documents named "Datasheet," which can be downloaded from the product page on our website.
